Standard signal S9648

Universal Standard Signal Panel Meter for Industrial Process Monitoring

The S9648 Standard Signal Panel Meter is a versatile digital display instrument designed for measuring, displaying, and monitoring industrial standard signals. Supporting 0/4–20 mA, 0–10 V, and potentiometer inputs, it provides accurate process indication with a high-brightness LED display. With an integrated 24 V transmitter supply, programmable scaling, optional alarm outputs, analog retransmission, and mathematical functions, the S9648 is ideal for modern industrial automation and control systems.

Key Features of Standard Signal S9648

Standard Signal S9648 is a standard signal panelmeter designed for measuring 0/4–20 mA, 0–10 V DC, and potentiometer signals. It includes an integrated transmitter supply for direct connection of 2- and 3-wire transmitters.

📊 Universal Signal Inputs
Accepts 0/4–20 mA, 0–10 V, and potentiometer inputs, making it compatible with a wide variety of industrial transmitters and sensors.

🔴 High-Brightness LED Display
Features a 14.2 mm red LED display with a programmable display range of ±9999 digits for clear and accurate process value indication.

⚡ Integrated 24 V Transmitter Supply
Provides an internal 24 V DC transmitter supply for direct connection of 2-wire and 3-wire transmitters, reducing installation complexity.

Key Features:

🚨 Up to 4 Alarm Outputs
Supports up to four relay or transistor outputs with programmable switching points, hysteresis, and delay functions for process alarms and automation.

📡 Optional Analog Retransmission
Available with isolated 0/4–20 mA or 0/2–10 V analog output for transmitting measured values to PLC, DCS, or SCADA systems.

🧮 Advanced Mathematical Functions
Optional second measuring input supports difference, average, minimum, and maximum value calculations, enhancing process monitoring capabilities.
