Standard signal S1010

Universal Standard Signal Meter for Industrial Process Monitoring

The S1010 Standard Signal Meter is a versatile industrial panel meter designed for displaying and monitoring standard process signals such as 0/4–20 mA and 0–10 V DC. With an integrated 24 V transmitter supply, freely programmable display scaling, optional alarm relays, and analog retransmission, it provides a reliable and cost-effective solution for industrial process indication and control. Housed in a rugged IP65 field enclosure, the S1010 is ideal for demanding industrial environments.

Key Features of Standard Signal S1010

Standard Signal S1010 is a field-mounted signal meter designed for displaying and monitoring standard 0/4–20 mA and 0–10 V DC signals. It can also provide an integrated transmitter supply for compatible 2- and 3-wire transmitters.

📊 Universal Standard Signal Input
Accepts 0/4–20 mA, 0–10 V DC, and potentiometer inputs, making it compatible with a wide range of industrial transmitters and sensors.

🔴 High-Visibility LED Display
Features a 14.2 mm red LED display with a programmable display range up to ±9999 digits, ensuring clear process value indication.

⚡ Integrated Transmitter Supply
Provides an integrated 24 V DC transmitter power supply for direct connection of 2-wire and 3-wire transmitters, simplifying installation and reducing external components.

Key Features:

🚨 Optional Alarm Outputs
Supports up to 2 SPDT relay outputs for configurable high/low alarms, process monitoring, and control applications.

📡 Optional Analog Output
Available with 0/4–20 mA or 0/2–10 V analog retransmission for seamless integration with PLC, DCS, and SCADA systems.

🛡️ Rugged Field Housing
Designed with a durable PA6-GF field enclosure featuring IP65 front protection, making it suitable for industrial installations.
